BASYS® Solar-Powered Deck-Mounted Mid Body
Request a Custom Spec
Don't see a variation that matches what you're looking for? You can request a custom spec from us with the exact options you want. Just click the button and fill out the form.
Features
Commercial Grade, ADA Compliant, Electronic, Sensor-Activated, Die-Cast Metal Hand Washing Faucet with the following features:
- One tool service
- All wetted components to be stainless steel, engineered thermoplastic, EPDM, and copper or copper alloy
- Solenoid housed in removable carrier that includes supply strainer
- Integral water supply shut off
- Supply strainer serviceable from above deck
- Vandal resistant spray insert, key housed inside faucet body
- All electronics sealed to IP-67
- Gold plated electrical contacts
- Above deck individual diagnostic indicators for battery life, solenoid condition, and power up mode
- Flexible, high pressure supply hoses, 3/8” compression connections
- Bi-stable magnetic solenoid
- Four (4) “AA” alkaline batteries
- Double infrared sensors with automatic setting feature
- Single hole installation
- Includes all mounting hardware
- Line purge mode, eliminates stagnant water
- Adjustable time-outs
- 3 year limited warranty
Specifications
Details
Flow Rate
Mounting Type
Sensor Type
Spray Type
Trim Plate
Warranty/Certification
Limited Warranty
3 Year
Compliances & Certifications
ADA Compliant , ASME A112.18.1 Compliant , CalGreen Compliant , CEC Compliant , cUPC Certified , UPC Certified , UPC Low Lead Compliant , cUPC Low Lead Compliant , EPD , GPC 0.25 or less , HPD , NYC604.4 , Proposition 65 , Satisfies LEED Credits , TAS , WELL Building Standard
Videos
Used in Projects...
